September 20, 2017
Rain Gardens Beautify Neighborhoods, Clean the Air and Reduce Pollution in Newtown Creek
A Map of Rain Garden Locations and Photos are Available on DEP’s Flickr Page
The Departments of Environmental Protection (DEP) and Design and Construction (DDC) today announced the completion of a $7.3 million project to construct approximately 300 specially designed rain gardens in the Queens neighborhoods of Sunnyside, Maspeth and Ridgewood. Each rain garden has the capacity to collect and absorb up to 2,500 gallons of stormwater when it rains. Modeling shows that all the rain gardens combined will capture an estimated 38 million gallons of stormwater each year, thereby easing pressure on the sewer system and reducing overflows into Newtown Creek. DEP funded the project and the construction was managed by DDC. To view a video of a rain garden collecting stormwater go here.
“Improving the health of Newtown Creek is a priority for DEP and we are excited that these completed rain gardens will capture stormwater, thereby reducing the amount of pollution that enters the waterway,” said DEP Acting Commissioner Vincent Sapienza. “This $7.3 million investment in green infrastructure will also beautify the streets and sidewalks of Maspeth, Sunnyside and Ridgewood, as well as help improve air quality.”
“Rain gardens can bring many benefits to Maspeth, Sunnyside, and Ridgewood, including a cleaner Newtown Creek,” said DDC Acting Commissioner Ana Barrio. “Rain gardens also improve the City’s ability to manage potential flooding, and introduce new green spaces to communities. We’re very pleased to work with DEP to make these improvements.”
“Every drop of stormwater kept out of our local sewers is a tangible step towards improving water quality in Newtown Creek. Specific tributaries, like Maspeth Creek and Dutch Kills, face significant environmental harm from combined sewage overflow and need continued attention and investment to meet Clean Water Act standards. We are encouraged to see these new rain gardens and look forward to DEP pursuing more well-planned and well-maintained Green Infrastructure in the future,” said Willis Elkins, program manager at Newtown Creek Alliance.
Rain gardens are built in city sidewalks and do not result in the loss of any parking spaces. They resemble standard street tree pits, except that they vary in size, have curb cuts that allow stormwater to enter and overflow if it becomes saturated, and have been designed in a way that will allow them to manage up to 2,500 gallons each during a storm. DEP has developed standard designs, specifications and procedures for building green infrastructure in the streets and sidewalks of New York City. In partnership with the Departments of Transportation and Parks and Recreation, DEP conducts an extensive site selection process that includes geotechnical investigations and surveys. During construction, the rain gardens are excavated to a depth of about five feet and are then backfilled with layers of stone and engineered soil. These layers contain void spaces that store the stormwater and promote infiltration. The addition of hardy plants further encourages infiltration through root growth and increases the capacity of the rain garden through evapotranspiration. The rain gardens are designed so that all the stormwater is absorbed in less than 48 hours and dedicated maintenance crews ensure that they are functioning properly, including removing any trash that may have accumulated and pruning the trees and plants. The crews are active seven days a week, visit each rain garden approximately once a week and additional crews will continue to be added as the program expands. To date, more than 3,000 rain gardens have been built throughout New York City with 1,500 currently under construction and thousands more planned for the next several years. A map of all constructed green infrastructure and that which is planned for future years is available here.
DEP primarily builds rain gardens in neighborhoods that are serviced by combined sewers. Within these neighborhoods, locations for the rain gardens are initially chosen by DEP engineers who, armed with maps of the local sewer systems, walk the streets and identify sidewalk locations that are upstream of a catch basin and have the room necessary to accommodate a garden. This initial group of potential locations is then reviewed by the Department of Transportation to ensure that they meet all necessary pedestrian and vehicle clearance requirements and the Department of Parks and Recreation who provides guidance on trees and planting plans. Soil samples are then taken from the approved locations to ensure they can absorb the necessary amount of stormwater. The extensive survey and testing ensures that each site functions as designed. The locations that meet all these requirements will then be approved for construction.
DEP has conducted extensive outreach in the Newtown Creek watershed area, including meeting with City Council Members, Community Boards 2 and 5, the Newtown Creek Alliance and numerous other neighborhood and environmental organizations. These meetings help to inform communities about the purpose of green infrastructure and the benefits it will bring to their neighborhoods, as well as plans for future construction. In addition, brochures with Frequently Asked Questions are distributed to the properties abutting the locations of future rain gardens.
New York City, like other older urban communities, is largely serviced by a combined sewer system where stormwater that falls on roofs, streets, and sidewalks, and wastewater from homes and businesses are carried through a single sewer line to treatment plants. The city’s 14 treatment plants can manage and treat to federal Clean Water Act standards all the wastewater produced in New York City on a dry weather day, or about 1.3 billion gallons on average. On a rainy day they have the capacity to clean more than twice the dry weather flows. However, during intense precipitation events, the stormwater that falls on the city’s impervious surfaces exceeds that capacity and overflows can be discharged into local waterways. If the overflows were not discharged, the City’s treatment plants would be flooded and severely damaged and wastewater could backup into homes and businesses.
Over the last decade the City has invested more than $10 billion in upgrades to wastewater treatment plants and related efforts to reduce combined sewer overflows and testing confirms that the water in New York Harbor is cleaner today than it has been in more than a century. However, overflows remain the city’s primary harbor water quality challenge. As traditional “grey” infrastructure upgrades became increasingly expensive, the NYC Green Infrastructure Plan was launched. An alternative approach to improving harbor water quality, it combines traditional infrastructure upgrades and the integration of green infrastructure to capture and retain stormwater runoff before it can ever enter the sewer system and contribute to overflows. New York City and New York State have entered into a Modified Consent Order which formalized the City’s inclusion of green infrastructure as an important component of its plan to reduce combined sewer overflows into local waterways and improve the ecological health and cleanliness of New York City harbor water.
